Handheld Single Channel ECG / EKG Machine

Handheld Single Channel ECG / EKG Machine

Call For Pricing : 1-800-507-8244
Skip to product information
Handheld Single Channel ECG / EKG Machine
  • Handheld Single Channel ECG / EKG Machine
Handheld Single Channel ECG / EKG Machine

Handheld Single Channel ECG / EKG Machine

Discount Cardiology
SKU#: Gen-001
In stock
Call For Pricing : 1-800-507-8244

Handheld Single Channel ECG / EKG Machine

Quick Review

Small 12 lead ekg machine that is Perfect for Insurance Examiners!
Documentation
  • Download Hand-Held Single Channel ECG Technical Parameters
  • Download Handheld Single Channel ECG / EKG Machine Cardiograph
Download Document of Handheld Single Channel ECG / EKG Machine
Shipping

Discount Cardiology ships via the Federal Express Service, which delivers shipments anywhere in the United States -- usually within 2-5 business days -- at low rates. Unless specified, shipping charges are added to each order based on the specific order.
Payment
Discount Cardiology
Description

We will beat any price in the country on this ekg machine!!

Hand-Held Single Channel ECG/EKG

Technical Parameters

1. Input circuit : Floating

2. Calibrating Voltage :1mV±5%

3. Input current :<100nA

4. CMRR :>103dB

5. A/D :12bit

6. Frequency Response: 0.05Hz--150Hz

7. Filter :AC 50/60Hz EMG: 35-4Hz

8. Skin Voltage Tolerance :±300mV

9. Sensitivity Setting 5 10 20mm/mV, conversion deviation≤5%

10. Noise Level :≤15Vp-p

11. Safety standard :IEC class I, type CF

12. Lead selection :Automatic and Manual

13. Operation mode :Automatic and Manual

14. Display :LCD 160*96 visual size: 34*60

15. Recording system :Thermal-array printing

16. Power supply: AC220V±10% DC 7.4 lithium battery

17. Size:190*90*40

18. Weight: 800g
